Beskrivelse
ES Maskiner Mobil nr 24674032 eller Mail. salg@esmaskiner.dk
Leasing tilbud.
Udbetaling 60.000 kr
Løber over 60 måneder.
Leasing i måneder 4332 kr.
Alle priser er excl. moms
| Dimensions:
|
Length | Width | Height | |||
| (mm) | (inch) | (mm) | (inch) | (mm) | (inch) | |
| Booth Exterior | 7050 | 23’2″ | 5250 | 17’3″ | 3600 | 11’10” |
| Booth Interior | 6900 | 22’8″ | 3900 | 12’10” | 2750 | 10′ |
| Entrance Size | 3000 | 9’10” | 2700 | 8’10” | ||
| Personnel Door | 800 | 2’7″ | 2000 | 6’7″ | ||
| Features: | Total Power 14.5 kw (220v /380v) | Noise < 80 db | |||
| Frame System | – Rockwool 50mm – for working temperature higher than 80 | ||||
| – EPS foam plate 75mm – for working temperature less than 80 | |||||
| Basement System | – 2 rows of grid plates & 3 rows of diamond plates | ||||
| Heating System | – Diesel burner 200000 kcal, Oil consumption 6 ~ 8 kg/h | ||||
| – Heating exchanger – stainless steel | |||||
| – Working temperature 60 ~ 80 ℃ | |||||
| – 20-30 minutes to get to working temperature | |||||
| Air System | – 2 sets of intake fans, 4 kw each, air flow 28000 m3/h total | ||||
| – 1 set of exhaust fan, 4 kw, air flow 14000 m3/h total | |||||
| – 0.3 m/s air speed | |||||
| Filter System | – Dual filtering – primary filter + ceiling filter | ||||
| Illumination | – 8×4 tubes (48″ long, 36w lamps) on the ceiling | ||||
| – 6×4 tubes (48″ long, 36w lamps) on the wall | |||||
| E-controlling System | – Spray & Baking Switch, Light Switch, Emergency Stop, Breakdown Alarm | ||||
| ** Included | – All hardware, fasteners, and sealants, A couple of ramps | ||||
| *** Optional | – Infrared Lamp alternative, about 20 kw | ||||
| – Water-proof roof optional for outdoor booth installation. | |||||
