Powder coating system for 5 m workpieces

New Powder Coating System from ES Maskiner ApS – Efficient and Energy-Saving

At ES Maskiner ApS, in collaboration with our partner in spray booths, we have created an attractive package solution for you who want a new powder coating system.

Specifications and Benefits:

Capacity:
The system can handle workpieces up to 5 m in length, and the oven door dimensions are 2×2 m.

Energy consumption:

With oil heating:
Only 19 kW of electricity per hour and 8–12 litres of oil per hour, equivalent to approx. DKK 158 per hour – a highly economical solution.

With electric heating:
Total power consumption is 82 kW per hour, equivalent to approx. DKK 164 per hour – still a very cost-effective solution.

Flexibility:
The system can be adapted to your needs, with the option of both oil and electric heating.

Why choose us?
With this solution, you get a modern and energy-efficient system that is ideal for both small and large production runs. It is developed with a focus on minimising operating costs while delivering high-quality powder coating.

Contact us for more information
Would you like to hear more about this solution or get a quote tailored to your business?
📧 salg@esmaskiner.dk
📞 +45 2467 4032
🌐 www.esmaskiner.dk
Let us help you optimise your production! 🚀

We can offer leasing on all our machines

Description

Powder Coating Systems from ES Maskiner ApS – Efficiency, Precision and Quality

At ES Maskiner ApS, we offer advanced powder coating systems that combine innovation and high performance. Our solutions are tailored for professionals who require efficiency and reliability for treating and coating large and small workpieces. Read more about why our powder coating systems are the perfect choice for your business.

Features and Benefits of Our Powder Coating Systems

1. Efficient Oven Technology:

Internal dimensions: 5500×2100×2000 mm, with a maximum temperature of 230°C.
Fast heat-up in just 20–25 minutes to reach 180°C.
Energy savings: Italian-made Riello G20 gas burner ensures low oil consumption (8–18 kg/h) and reduced operating costs.

2. Spray Booth – Quick and Easy Colour Change:

Internal dimensions: 6000×2500×2200 mm, enabling processing of larger workpieces.
Made from PP materials, which prevent powder from sticking and make cleaning easy.
Dual recovery system: Nano-coated filter technology captures dust and ensures clean air, reducing the need for external extraction.

3. Innovative Transport System:

Heavy-duty trolley frames: Easy 360-degree movement with universal wheels and a load capacity of up to 300 kg per unit.

4. Advanced Control and Automation:

Digital control system with pulse control, temperature regulation and fault indicators.
Option for fully automatic control, reducing manual intervention and optimising workflows.

5. High Safety and Durability:

Wall panels of 150 mm rock wool sandwich with fire-safe and heat-insulating properties.
Robust, galvanised steel doors ensure durability and easy access to the booth.

Technical Specifications – Overview:

Oven system:

Internal size: 5500×2100×2000 mm.
Oil-based heating with high energy efficiency.

Spray Booth:

Dimensions: 6000×2500×2200 mm.
Nano filters and integrated fans (7.5 kW) with an airflow of 5000 m³/h.

Powder recovery:

Dual recovery system with 12 nano-coated filter cartridges, ensuring environmentally friendly operation.

Control system:

Automatic reverse blow for filter cleaning, independent control of fan and light, and temperature settings.

Why Choose ES Maskiner ApS?

Tailor-made solutions: We adapt the system to your needs.
Energy efficiency: Reduce operating costs with our advanced oil and filter systems.
Sustainability: Designed with a focus on environmentally friendly processes and recycling.
Support and service: Get professional guidance and technical support when you buy from us.

Would you like more information about our powder coating systems or a tailor-made solution for your business? Visit our website www.esmaskiner.dk or contact us directly for a non-binding quote.

ES Maskiner ApS – Your expert in powder coating and industrial solutions.
